My rambling thoughts on exploring the .NET framework and related technologies
Home of the surprisingly popular Pixata Custom Controls For Lightswitch (well, it was a surprise to me!)

As my regular reader will know, when Lightswitch came out, I was quickly hooked. Like many people, I saw an answer to the hassle of creating n-tier desktop applications. It was a dream. Development time was slashed, and the few annoyances that there were paled into insignificance compared to the speed of development, and the quality of the end product.

I dived in head-first, and quickly came up against some of the limitations of a first version. That’s not a criticism, it’s more a testimony to the amazing power the first version had, that we could produce real LOB applications, and were frustrated by the missing bits.

Thankfully, Microsoft did a sterling job of adding extensibility points to Lightswitch, and despite the poor documentation (an ongoing feature of Lightswitch that caused a lot of wasted hours), the potential was there to fill in the gaps.

Inspired by early experimenters, like Yann Duran’s excellent Luminous Controls (which I still use in every Lightswitch project), I had a go at producing a custom control for Lightswitch, more for the fun of tinkering than anything else. Having worked out how to get going, I added a few more controls, until the first version of the Pixata Custom Controls For Lightswitch was born. Feeling that I had something that might be of use to others, I added it to the Visual Studio Gallery, and posting about it in the (now extinct) forum. I got so excited when it had 100 downloads!

Spurred on by the great feedback, I added more controls, and the control suite hit the top three for Lightswitch extensions. It varied between the first, second and third places, but has always been in the top three. To date, it’s had over 25,000 downloads, despite that the fact that I haven’t updated the controls for over a year.

Roll on a few years, and the mobile market exploded. Smartphones and tablets gained more power, and were able to browse the web almost as well as their desktop cousins. However, probably due to political more than technical reasons, the manufacturers chose not to support Flash or Silverlight on these devices, leaving Lightswitch out in the cold.

Microsoft, fairly understandably, decided to concentrate their efforts on producing a version of Lightswitch that would support mobile devices. That's where the HTML client came in.

This was fine, except for two huge problems...

1) The HTML client was (and still is from what I can see) woefully short of being ready for the job. It's a good start, but not good enough to create LOB applications. Specifically, despite the massive growth of the mobile market, Microsoft seem to have forgotten that the desktop world still exists, and still accounts of a very significant number of users, especially in the business world. Until the HTML client supports the desktop, it can't be considered ready for serious use.

I have other misgivings about the HTML client, but they are minor in comparison to this one. I know the mobile market is important, but in business-to-business work, which is a significant part of the software development world, you just can’t afford to ignore the desktop.

2) Whilst I don't think we can criticise Microsoft for moving away from Silverlight, which must have been hard for them, having put so much effort into producing a first-class product, what is totally unforgiveable (in my opinion at least, and I know I'm not alone) is the way they just dumped the Silverlight developers without any support. Their support for the more advanced side of Lightswitch was always poor, but when the HTML client came along, Silverlight client developers were just ignored completely. The extensibility forum died a sudden death, with unanswered questions making up the sum total of all posts.

Now, before I get criticised for this, I understand that they have limited resources, and want to concentrate their efforts on the latest and greatest, but many, many developers sunk a large amount of time and energy into Silverlight-related development, and to have all support cut off in an instant was a really dirty trick. I think we can all understand why they don’t want to invest more time in active development, but at least support what’s already there.

The problem became more acute as time went on, and Microsoft were pushing the HTML client with an evangelical fervour. It got to the stage where I knew that if I had a problem, there was little point in posting in a forum, as my post would be swallowed in a sea of HTML-related questions, and wouldn’t be answered by anyone at Microsoft anyway. The only way I could get an support was peer-to-peer support from some of the Lightswitch rock stars.

It came to a head for me recently when, having invested a significant amount of time in developing a complex application, it suddenly stopped working. The only clue I had was the rather generic error message “Cannot communicate with the database” when the application started. It worked fine on my development machine, and the database connections were all correct (I could even change the connection strings in Visual Studio, and run the application against the remote production database, so I know that wasn’t the problem), but the deployed version refused to work.

After struggling to get the attention of any Microsoft support person, I eventually had to give up and rewrite the entire application in WPF and ASP.NET WebAPI2. Surprisingly, it didn’t actually take that long, and left me wondering if Lightswitch is really as RAD as I had thought, once you get away from the basic functionality.

So, I’m left with a sour taste in my mouth, and some deployed Lightswitch applications that I’m terrified to touch, in case they mysteriously stop working as well. I can’t afford to rewrite them from scratch, and know that there is no way I’ll get any support if they stop working. I’m just hoping the customers don’t want any changes.

Sad end to a promising product. I have little interest in investigating the HTML client, as ASP.NET MVC makes it so easy to produce high-quality web sites that work in both desktop and mobile environments, and I can’t see any benefits in Lightswitch for this.

As for the controls? Well, I’ve made them open source, so if anyone wants to develop them further, they can.

Categories: LightSwitch | Microsoft | Silverlight
# Scott Hanselman on Java in the 1990s (Thursday, June 13, 2013)


Writing Java was like watching a three-legged dog. You know he's going to get where he wants to go, but it's just really sad to watch.

Categories: Computers

Last February, I hit a problem where I was trying to implement printing from a Lightswitch screen, and was using what has now become known as the Command Table Pattern, which allows the Lightswitch client to send a command to the server. I was encountering an error with the witty message “A new instance of the EntityObject class cannot be initialized because the ambient IDataWorkspace is not available. Please use the constructor that specifies an EntitySet” which was as clear as mud to me!

I asked about this in the Lightswitch forum, and was greatly helped by the ace Lightswitch insider Justin Anderson, who patiently explained that the problem I was facing was to do with threads, dispatchers and workspaces. This area is one of those that seems to trip up a lot of people when they start digging into Lightswitch, and is very poorly documented. The few articles I have seen are fairly difficult to understand, which only compounds the problem. Thanks to Justin’s help, I got my code working, and got a better understanding of the subject.

Well, a few weeks ago, Steve added a comment to that forum post, as he was having a very similar problem when trying to create a new entity in the Click event handler of my Pixata Static Toolbar control. As I tried to explain what the problem was, I ended up explaining threads, dispatchers and workspaces, as he had hit exactly the same lack of understanding of these that led me to make the post in the first place.

He seemed to like my explanation, so I decided to post it here, as it may help someone else. Let me say in advance that this is not a comprehensive explanation, nor is it totally accurate, because it's a complex subject and I want to try and explain it in a way you'll understand. If any Lightswitch gurus are disgusted at my explanation, please feel free to leave a comment below, or email me Smile

Let’s deal with threads first...

In order to keep the UI responsive, Lightswitch uses two threads (think of two small men inside your PC, each one doing something different, but talking to each other to keep their work in synch). The main thread, let's call him Fred, handles getting data from the server and sending it back again. The other thread, whom we'll call Jim (because Jim is a good name) handles the UI stuff, like making sure the textboxes and comboboxes are drawn on the screen, and contain the right data.

When you do things like typing, choosing from a combobox, etc, you are talking to Jim. When you hit the Save button, this sends a message to Fred. You don't talk to Fred directly like you do to Jim, as Fred is in the background, round the back of your monitor where all the dust and dead flies collect, so when you click the Save button, what really happens is that Jim sends Fred a message saying "Here Fred, this one is for you." When Fred gets the message, he sends the data to the database for you.

The tricky bit is that there are two ways that the user tells Lightswitch what to do. One is through commands, which is how you work when you add a method to the screen (Click the "Add Data Item" button and choose "Method"). This sets up a command that just tells Jim to send a message to Fred, and have Fred do the work. However, if you capture control events, such as a button's Click event, then you are asking Jim to do the work himself, and not get Fred involved at all (he's cleaning up the dead flies while he's nothing better to do).

If that hasn't confused you, then you might have a very general (and rather flippant) idea of how threads work. When you are in a method created as a data item, you are talking to Fred, and Lightswitch creates a DataWorkspace for you. When you are in a control event handler, you are talking to Jim, and there isn't a DataWorkspace around. If you want one, you have to create one.

Aside: As my regular reader will know, I’m a huge fan of Lightswitch, but I do have one big gripe with it, and I think this is the cause of a lot of confusion to new Lightswitch programmers. In the name of good software design, Microsoft used the MVVM pattern when building Lightswitch. This is a familiar pattern to WPF and Silverlight programmers, and (like MVC and MVP before it), allows a clean separation of the business layer from the UI layer.

Now, in a normal (ie WPF or Silverlight application), the view model is in a completely separate file from the view. Thus, command methods are nowhere near control event handlers, which helps keep the separation clear in the mind of the programmer.

However, in Lightswitch, the view model code is in the same file as the screen’s code, meaning that you have methods sitting right next to each other that are actually going to be executing on different threads. I think this is a very bad idea, and seems to be the source of many problems I’ve seen in the forums.

Anyway, gripe over, back to Fred and Jim...

So, if we have two threads, how do they communicate? That’s where dispatchers come in. Dispatchers are a way of having Fred pass work to Jim and vice versa.

Certain tasks need to be done by Fred, as he works with the data. However, if you are inside a control event handler, then you are talking to Jim. So, what you need to do is ask Jim very politely if he will send a message to Fred asking him to do the work. That's where dispatchers come in.

You have two dispatchers, one that passes (ie dispatches) the work to Fred (also known as Main, as he handles the main work), and one that passes the work to Jim (known as Details). Remember, when you're writing code in a control event handler, you're talking to Jim, ie to the Details thread. For example, if you are in a control’s event handler, and you want to create a new entity (as Steve was), you need to pass the job to Fred, meaning that you need to use the Main dispatcher.

In Steve’s case, he didn't actually need a dispatcher, as he could have handled the problem a different way, but if he had, he would have needed the Main dispatcher, as he was already talking to Jim (remember the code was in a control event handler), and he wanted to pass the work to Fred. In such a case, you would do something like this...

    Dispatchers.Main().BeginInvoke(Sub()
      ' code for Fred to do goes here
    End Sub)

(Note that Steve was working in Visual Basic.NET, which is why I departed from the norm and didn’t use C# above)

I hope this has helped. If it's any consolation, I think dispatchers are about the most complex bit of Lightswitch there is. Hopefully, if you read the above a few times, it might make some sense. If you run into exceptions to do with threads, chances are you need a dispatcher. There are two ways to work out which one you need to use. The first is good old trial and error! Try one, and if it doesn't work, try the other. This isn't really a good approach, as you don't really get to understand what you're doing. The second approach is to keep reading and trying to understand it until it goes in.

The easiest way to think about it, which will probably work for you in most cases, is that if you are coding in an event control handler, then if you need to dispatch, you use Dispatchers.Main().BeginInvoke. If you are in a data item method, then you will need to dispatch using Me.Details.Dispatcher.BeginInvoke.

Although the DataWorkspace side of this issue is less commonly encountered, I might as well add on a quick overview of that, as it was relevant to the forum post. In simple terms, the DataWorkspace is what you use when dealing with data in Lightswitch, and one is created for you in the view model. However, when working in the screen’s code-behind, you don't have one, which is why the error message shown at the top appears. If you need to access data from an event handler, you’ll probably need to grab your own DataWorkspace.

In my original case (which is the same as Steve’s), I was trying to create a new entity. The entities that Lightswitch creates from your database have a parameterless constructor that uses the ambient DataWorkspace, meaning the one that Lightswitch creates for you (ambient = hanging around counting dead flies, waiting for you to do something that it knows about). If you are in a view model, then this works fine, which is why you generally don’t have to worry about DataWorkspaces, as most of your code should be written in the view model.

However, sometimes you need to do this stuff in event handlers, and you don’t have an ambient DataWorkspace hanging around. In this case, you need to use another entity constructor that takes a DataWorkspace as a parameter. In my case, this meant doing this...

  new InvoiceAction(this.DataWorkspace.MyAppData.InvoiceActions);

All this does is grab hold of a DataWorkspace explicitly, and pass it to the entity’s constructor. Once you know about this, the error message at the start of this article makes more sense, but when you first encounter it, your eyes start to glaze over, and you wonder why there are so many dead flies behind your monitor (Fred has been too busy dealing with your errors to clean them out).

I hope this has been helpful to someone! If you have any comments, or would like to hear how Fred and Jim are getting on, please click the “Comments” link below and let me know.

Categories: LightSwitch
# Two cute programmer jokes (Tuesday, October 30, 2012)


This one amused me...

protected void On_DayLoad(object sender, EventArgs e) {
  Beverage coffee = new Beverage("coffee");
  coffee.Add(Beverage.Sweetener.Sugar);
  coffee.Cream = false;
  Cup mug = new Cup();
  mug.Add(coffee);
  Me.Consume(mug);
  mug.Dispose();
}

Of course, you could argue that the hard-coded string in the Beverage class constructor is bad design, but it’s only a joke eh?

This one is an old one, but I liked the variation of answer...

Question: How many programmers does it take to change a light bulb?

Answer 1: None, it's a hardware issue

Answer 2: A properly designed light bulb object would inherit a Change() method from a generic base Lighting class, so all you'd have to do is send a light bulb change message

Categories: Computers

Why a toolbar control?

A month ago, I posted an article showing how to create a custom toolbar for a Lightswitch application. At the time, I thought that this was so easy that there was little point in creating a control extension for it. However, the more I thought about it, the more I realised that whilst it’s very easy for an experienced programmer, it wouldn’t be quite so easy for someone with less experience. Furthermore, easy as it was, it still requires you to build the toolbar yourself and write the code.

This niggled me enough to have a go at creating a control extension to implement the toolbar. Along the way I learned some new Lightswitch tricks, and ended up with a control that’s even easier to use than writing your own!

You’ll need the latest version (1.15, published today on the Visual Studio Gallery) of the control extension to follow along. Imagine we have a Lightswitch application that maintains contact details for ferrets (as you do!). We have a list and details screen that displays the ferrets’ information, and want to add a toolbar above the details side to allow the user to change the selected ferret’s name. This is a contrived example, but was the best I could think up on the spur of the moment and with little sleep! For a more realistic example of why you might want a toolbar, see my previous blog post.

Here’s a screen shot of what we’re aiming for...

A static toolbar in action

Regular readers will recognise the dear elephant that has graced this blog several times. The other icons come from my usual source, www.findicons.com, although I recently discovered some great free icons at www.proicons.com. One of the good things about that site is that the icons are organised into themes, rather than being a random collection of individual icons like www.findicons.com. Anyway, you can see that the toolbar above has five buttons, three with just an image, one with an image and text, and one with just text. The Pixata Static Toolbar control allows you to choose how your button will look (including completely restyling it if you want, see later).

Using the toolbar control

To use the control, click the “Add A Data Item” button on the Lightswitch designer window, and add a new Local Property. As with all the static controls, this is merely to get around the Lightswitch limitation of requiring all controls to be bound to something, so you can leave it as a string (uncheck the “Is Required” checkbox) and name it anything you like. I tend to call mine StaticProperty, as it helps me remember what it is when looking at the designer, but you can call it anything you like.

Drag this property onto the designer wherever you want the toolbar to appear, and change the control type to Pixata Static Toolbar control...

Choosing the Pixata Static Toolbar control

Setting the button properties

Have a look in the Properties panel. The first three properties apply to all buttons in the toolbar. The “Image width” and “Image height” properties set the size of the images to be displayed on the buttons. For simplicity (and to make the toolbar look nicer), you have to set the one width and one height, and this will be used for every button. Next you can set the margin for the button. The default is “0,0,5,0” which gives 5 pixels space to the right of each button, so they don’t squash right up next to each other. You change this to whatever you like, but the default setting is probably all you’ll ever need.

After that, you’ll see five groups of properties that look like this...

The properties for a button

Unfortunately, I don’t think there is any way to group these visually, but you’ll see that there are five sets of identical properties. The checkbox specifies if the button is displayed or not. The toolbar allows you up to five buttons, but also allows you less by clearing the checkboxes. If you want more than five buttons in a toolbar, just add two of them.

The link below the checkbox allows you to select the image that will be used for the button. The text for the button is shown next. If you just want an image on the button (like in the 1st, 3rd and 5th buttons in the screen shot at the top of this post), then leave this property blank. If you choose an image and enter text, you’ll end up with both, like the 2nd button in the screen shot earlier. If you just enter text and don’t choose an image, then you’ll end up with a text-only button, like the 4th button above. This last option isn’t that exciting, as you can do this in Lightswitch alone.

The tooltip is the text that will be displayed when your mouse hovers over the button. In the screen shot earlier, my mouse (which you can’t see) was hovering over the 2nd button, and the tooltip text is displayed.

The “Tag text” property allows you to set the tag of the button to a string. The purpose of this will be explained below.

Handling the button click event

The only other thing you need to do is to handle the event when a button is clicked. This is the only place you need to write code to use this control. Click the “Write code” button in the screen designer, and choose the ScreenName_InitializeDataWorkspace event. The first thing you need to do is add the following line at the top of the file...

using PixataCustomControls.Presentation.Controls;

Then add the following lines inside the event handler that was created for you...

partial void FerretsListDetail_InitializeDataWorkspace(List<IDataService> saveChangesTo) {
  var toolbar1 = this.FindControl("FerretToolbar");
  toolbar1.ControlAvailable += (S, E) => {
    StaticToolbar stb = ((StaticToolbar)E.Control);
    stb.ButtonClick += new System.EventHandler<StaticToolbarEventArgs>(FerretToolbar_BtnClick);
  };
}

My toolbar is called FerretToolbar, so unless you’ve chosen the same name (welcome fellow ferret fan!), you’ll need to change that to match what you chose. By default, Lightswitch will name it after your static property, but you can change this to something more meaningful.

When the ControlAvailable event fires, the code above grabs the toolbar control (which I’ve stored in a local variable called stb), and then subscribes to the ButtonClick event, which will be fired whenever someone clicks one of the toolbar buttons. To make life easier, I only added one event instead of five.

All you need now is the event handler. Here is a sample...

void FerretToolbar_BtnClick(object sender, StaticToolbarEventArgs e) {
  FerretsSet.SelectedItem.Name = e.TagText;
}

This simple example simply updates the selected ferret’s name to the tag text of the button that was clicked. If your application requires similar behaviour for each button, then using the tag text is a great way to simplify the code. This is similar to the way I inserted standard text in the previous blog post. If you don’t set the tag text, then this will set the name to the empty string.

If you want to have your buttons do distinct things, then this isn’t necessarily the best way to go, as the tag text doesn’t give enough flexibility. In this case, you can just check which button was clicked, and branch appropriately. The ButtonClick event takes a StaticToolbarEventArgs object, that contains the tag text (as shown above), as well as the number of the button. Note that the buttons are numbered one to five and NOT zero to four, as I thought that was too confusing for the general user.

Here is a sample of how to handle this case...

void FerretToolbar_BtnClick(object sender, StaticToolbarEventArgs e) {
  switch (e.ButtonNumber) {
    case 1:
      DoButtonOneStuff();
      break;
    case 2:
      DoButtonTwoStuff();
      break;
  }
}

I’ve only shown two cases here to save some space, but it would work the same if you use more buttons.

Modifying the buttons as much as you like

I know that there are people out there who will immediately ask me if they can get hold of the individual buttons, so they can customise them like crazy! Well, I’m one step ahead of you! The control exposes an indexer, which allows you to get the actual buttons on the toolbar. Once you have the toolbar itself (as I did in the FerretsListDetail_InitializeDataWorkspace event handler earlier), you can just do this...

stb[1].Content = "New Text For Button #1";

This rather pointless example shows you how to set the Content for the button to a plain string. As mentioned above, you can do this from the Properties panel without needing code, or you can use a regular Lightswitch button (generated when you drag a method onto the designer surface). However, the point here is that stb[1] is the actual button, so you can do anything to it that you could do to a normal button, including replacing the Content with something of your own invention. I can’t think of any suitably weird example, so I’ll leave that to you dear reader!

Note again that the buttons are numbered from one to five, so if you attempt to access button zero, you will get an IndexOutOfRangeException exception.

One small niggle

One thing I found was that if you want a toolbar with more than five buttons, and you use two of my static toolbar controls next to each other, Lightswitch helpfully adds three pixels of blank space between them. It does this to all controls, so they don’t get all squashed up, but in this case, it is not desirable. I contemplated hacking around to try and remove these three pixels, but decided it wasn’t worth the effort, especially as most toolbars will not have more than five buttons that need to be together. You generally find that toolbars have their buttons in smaller groups, with a vertical divider between the groups. You can do this easily by using several static toolbar controls, and separating them with the Pixata Vertical Divider control. You’ll need to add something between the divider and the next toolbar, so that Lightswitch adds its three pixels. The easiest way to do this is use a Pixata Spacer Control, with the width set to zero.. .

The 1st and 4th controls in that Columns Layout are two static toolbars. The second control is the vertical divider (width set to 1), and the 3rd control is a spacer whose width is zero.

The result of this looks like this...

I hope you find this new control useful. As usual, if you have any comments or questions, please leave them on the Visual Studio Gallery page.

Update 24th Sept ‘12

For those using VB.NET, here is a sample of an entire screen code that does pretty much the same as the code above.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Imports PixataCustomControls.Presentation.Controls

Namespace LightSwitchApplication

Public Class Customers

Private Sub Customers_InitializeDataWorkspace(saveChangesTo As System.Collections.Generic.List(Of Microsoft.LightSwitch.IDataService))
  AddHandler Me.FindControl("FerretToolbar").ControlAvailable, AddressOf FerretToolbar_ControlAvailable
End Sub

Private Sub FerretToolbar_ControlAvailable(sender As Object, e As ControlAvailableEventArgs)
  Dim FerretToolbar As StaticToolbar = TryCast(e.Control, StaticToolbar)
  AddHandler FerretToolbar.ButtonClick, AddressOf FerretToolbar_ButtonClick
  ' Set properties here if you like
End Sub

Private Sub FerretToolbar_ButtonClick(sender As Object, e As StaticToolbarEventArgs)
  Customers1.SelectedItem.Name = e.TagText
End Sub

End Class

End Namespace
Categories: LightSwitch

As my avid reader will know, I’m a huge fan of Visual Studio Lightswitch, mainly for the ease and speed with which you can get an impressive CRUD (forms over data) application up and running. However, one of the (admittedly few) limitations that I’ve found is that you don’t have as much control over the user interface (UI) as you do in WPF, Silverlight or WinForms applications. Whilst this is generally not a problem, it can sometimes be a issue.

For example, I’m currently working on an application which generates emails and documents at various times. These are based on templates that the user can modify. In order to make life easy for them, I provided an editor in the application, and wanted to give them an easy way of inserting placeholder text that would be replaced when the email or document was generated. In order to add buttons for the placeholder text items, I added several methods to the screen, and dragged these to the designer to create the buttons. As they can modify document templates and email templates, and the latter have both a subject and body, I needed three buttons for every placeholder text in use. The email tab of this screen looked like this...

The Lightswitch application before the custom toolbar



As you can see, I placed the two sets of buttons on the right, so they would be easily accessible when typing the template.

The problem with this is that those buttons don’t look very pretty, and they take up quite a bit of screen space. The Documents tab has another set of buttons, for inserting text into the document body. Apart from the looks, this resulted in three almost identical sets of six almost identical screen methods, with the associated problems in maintenance. This bothered me enough to wonder how hard it would be to implement a custom toolbar for Lightswitch, that could be used three times, saving me all that almost identical code.

This turned out to be almost embarrassingly easy, as I will explain with a simple example.

A Simple Example

If you want to follow along, create a new Lightswitch application, and add a table called Customers. Actually, you can add anything you like, this was just the first (moderately sensible) thing that came into my head. The table looks like this...

The Customers table in the Lightswitch designer

Now create a “List and Details Screen” based on this table. At this stage, you can run the application and add some data - don’tcha just LURVE Lightswitch!

In a desperate attempt to think of something useful here, I decided that I wanted a quick way to increase the number of orders recorded for the customer (I know, this would normally come from somewhere else in the database, but bear with me, the point here is to show you how to make a toolbar, not how to write a sensible application!) and to update the date of last contact to the current date and time.

I could do this by adding two methods to the screen, and dragging them onto the designer, but this would look as ugly as the sample I showed above. We want our users to we wowed by the fab UI we gave them, so we’re going to add... elephants! Huh? Bear with me folks, it will all become clear.

To create the toolbar, switch to File View in the Solution Explorer, and find the Client project. Add a folder named UserControls to this project, and add a Silverlight User Control named CustomerToolbar.xaml to the folder. Your Solution Explorer should look something like this...

The solution explorer in Visual Studio when you've added the user control

Aside: Strictly speaking, you don’t need to add the folder, but it’s a good idea to help keep things separate. It’s also worth noting that you don’t need to put your user control in a separate project as many people claim. Unless you’re writing something that will be reused a lot, in which case you’re better of writing an extension, there’s no need to bother with a separate project. As far as I know, the way I have shown will also work with the Express version of Visual Studio, which doesn’t allow extra projects to be added.

Now double-click the CustomerToolbar.xaml file to open it up in the Silverlight designer. There are quite a few ways of creating a toolbar, and I chose to use a set of Button controls inside a StackPanel. My XAML looked like this...

<UserControl x:Class="LightSwitchApplication.UserControls.CustomerToolbar"
             xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
             xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
             xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
             xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
             mc:Ignorable="d"
             Height="40"
             Width="130">

  <StackPanel Orientation="Horizontal">
    <Button Height="40"
            Width="40"
            Margin="0"
            Name="BtnElephant"
            Click="BtnElephant_Click">
      <Image Source="/CustomToolbar.Client;component/Images/elephant.png"
             Height="32"
             Width="32" />
    </Button>
    <Button Height="40"
            Width="40"
            Margin="5,0"
            Name="BtnCoffee"
            Click="BtnCoffee_Click">
      <Image Source="/CustomToolbar.Client;component/Images/rss.png"
             Height="32"
             Width="32" />
    </Button>
    <Button Height="40"
            Width="40"
            Name="BtnBell"
            Click="BtnBell_Click">
      <Image Source="/CustomToolbar.Client;component/Images/alert.png"
             Height="32"
             Width="32" />
    </Button>
  </StackPanel>
</UserControl>

I took the easy approach to adding the images, by creating empty <Image> tags, then clicking the Source property in the Properties panel, clicking the Add button and navigating my way to the PNG file I was using. Visual Studio added the image to my project and set the Build Action to Resource for me. You can do this manually, but why bother?

The designer now looked like this...

The toolbar control in the Visual Studio designer



As you can see, we have an elephant, a coffee cup and a bell. All the icons came from www.findicons.com, my usual favourite source of free icons. I picked these three more for their looks than their significance to the task at hand. In a real application, you would want to pick something more meaningful. I also didn’t add tool tips in the XAML above. These are a good idea, and will be added in the final version shown later.

Now switch the Solution Explorer back to Logical View, and double-click the Customers screen you created earlier. We want to add the toolbar to our screen, but as you probably know, version 1 of Lightswitch only allows you to add data-bound items to a screen. We get around this by adding a Local Property to the screen. Click the “Add Data Item…” button at the top of the window, then choose “Local Property,” uncheck the “Is Required” checkbox and give it a name. I tend to use StaticProperty, as this helps me remember what it is, but you can call it anything you like.

Now drag the property onto your screen wherever you want the toolbar to appear. In my case, the screen is a “List and Details” screen, and I want the toolbar above the details section. Once it’s on the screen, change the control type to Custom Control, and in the Properties panel, click the “Change” link. From the window that appears, choose the control...

The window where you can pick the custom control

My screen designer now looked like this...

The Lightswitch screen designer when the custom control has been added

If you run the application now, you’ll see the toolbar looking very smart...

The toolbar on the Lightswitch application

Looks very nice, but it doesn’t to anything yet. We’ll fix that right now.

In order to have the toolbar notify the Lightswitch screen when someone clicks a button, we’ll add some event handlers to the code. Switch to the code-behind file for the control, which in my case is called CustomerToolbar.xaml.cs (you’ll need to be in File View to see this), and change the code to look like this...

using System;
using System.Windows;
using System.Windows.Controls;

namespace LightSwitchApplication.UserControls {
  public partial class CustomerToolbar : UserControl {
    public CustomerToolbar() {
      InitializeComponent();
    }

    public event EventHandler Elephant;

    private void BtnElephant_Click(object sender, RoutedEventArgs e) {
      EventHandler eh = Elephant;
      if (eh != null) {
        eh(this, null);
      }
    }

    public event EventHandler Coffee;

    private void BtnCoffee_Click(object sender, RoutedEventArgs e) {
      EventHandler eh = Coffee;
      if (eh != null) {
        eh(this, null);
      }
    }

    public event EventHandler Bell;

    private void BtnBell_Click(object sender, RoutedEventArgs e) {
      EventHandler eh = Bell;
      if (eh != null) {
        eh(this, null);
      }
    }
  }
}

In this case, I’ve added three separate event handlers, one for each button. This is fine if each button does something quite different. In the case of my original application, all the buttons are to do a very similar task, so we can make the code easier, as I’ll show soon. Also, you would probably want to refactor this code to make it slimmer, as there is a lot of almost identical code here. I didn’t bother for this simple example, but will show how this could be done later.

Back in the Lightswitch screen code behind, we simply need to catch the toolbar’s events, and then do whatever we want in response. For the purposes of this demo, I’m going to have the elephant button increase the number of orders for the current customer, and the coffee button set the date last contacted to the current date/time. Here is the complete screen code...

using System;
using System.Collections.Generic;
using LightSwitchApplication.UserControls;
using Microsoft.LightSwitch;
using Microsoft.LightSwitch.Presentation.Extensions;

namespace LightSwitchApplication {
  public partial class CustomersScreen {
    partial void CustomersScreen_InitializeDataWorkspace(List<IDataService> saveChangesTo) {
      this.FindControl("Toolbar").ControlAvailable += (S, E) => {
        ((CustomerToolbar)E.Control).Elephant += new EventHandler(CustomersScreen_Elephant);
        ((CustomerToolbar)E.Control).Coffee += new EventHandler(CustomersScreen_Coffee);
        ((CustomerToolbar)E.Control).Bell += new EventHandler(CustomersScreen_Bell);
      };
    }

    void CustomersScreen_Elephant(object sender, EventArgs e) {
      if (CustomersSet.SelectedItem != null) {
        CustomersSet.SelectedItem.NumberOfOrders++;
      }
    }

    void CustomersScreen_Coffee(object sender, EventArgs e) {
      if (CustomersSet.SelectedItem != null) {
        CustomersSet.SelectedItem.DateOfLastContact = DateTime.Now;
      }
    }

    void CustomersScreen_Bell(object sender, EventArgs e) {
    }
  }
}

As you can see, in the InitializeDataWorkspace event, we grab the toolbar control and set up handlers for the three events. In the event handlers themselves, we set the customer’s properties. I haven’t done anything in the third event handler here, mainly because I couldn’t think of anything useful, given the limited scope of this simple example!

If you run the application now, you’ll find that the elephant and coffee cup buttons work as expected (assuming you expect an elephant to increase the number of orders, and a coffee cup to set today’s date of course!). We have a fully working toolbar, with amazingly little effort.

In this sample, I have added a separate event handler for each button, which is fine when the buttons do quite distinct tasks, as these do. In the original application I showed at the top, the buttons all do a very similar job, so we can improve this control quite a lot...

Tidying Up The Toolbar Code

As I mentioned above, my original case was where I wanted the buttons to insert standard bits of text into controls on the screen. As each button on the toolbar is to do basically the same job, with only a variation in the actual text, we can set up one event in the toolbar control, and use an EventArgs class to pass the text back to the Lightswitch screen.

Imagine the requirements for our sample app have changed, and we now want to set the Customer Name to one of three specified bits of text, depending on which button is pressed.

Switch to File View again, and in the same folder where you created the user control, add a class called CustomerToolbarEventArgs, whose code should look like this...

using System;

namespace LightSwitchApplication.UserControls {
  public class CustomerToolbarEventArgs : EventArgs {
    public string Text { get; set; }
  }
}

This class adds a single string property to the standard EventArgs class, which we’ll use to pass the text to be inserted back to the Lightswitch screen.

Change the toolbar control’s code to look like this...

using System;
using System.Windows;
using System.Windows.Controls;

namespace LightSwitchApplication.UserControls {
  public partial class CustomerToolbar : UserControl {
    public CustomerToolbar() {
      InitializeComponent();
    }

    public event EventHandler<CustomerToolbarEventArgs> BtnClick;

    private void FireEvent(string Text) {
      CustomerToolbarEventArgs Ev = new CustomerToolbarEventArgs {
        Text = Text
      };
      EventHandler<CustomerToolbarEventArgs> eh = BtnClick;
      if (eh != null) {
        eh(this, Ev);
      }
    }

    private void BtnElephant_Click(object sender, RoutedEventArgs e) {
      FireEvent("I like buns!");
    }

    private void BtnCoffee_Click(object sender, RoutedEventArgs e) {
      FireEvent("No sugar please!");
    }

    private void BtnBell_Click(object sender, RoutedEventArgs e) {
      FireEvent("Ding dong!");
    }
  }
}

As you can see, we now only have one event handler, which is generic to the CustomerToolbarEventArgs that we created above. The Click event handlers for the three buttons call a common method that sets up an instance of this class, and raises the event.

Now, we can simplify the Lightswitch screen by changing the code to this...

using System;
using System.Collections.Generic;
using LightSwitchApplication.UserControls;
using Microsoft.LightSwitch;
using Microsoft.LightSwitch.Presentation.Extensions;

namespace LightSwitchApplication {
  public partial class CustomersScreen {
    partial void CustomersScreen_InitializeDataWorkspace(List<IDataService> saveChangesTo) {
      this.FindControl("Toolbar").ControlAvailable += (S, E) => {
        ((CustomerToolbar)E.Control).BtnClick += new EventHandler<CustomerToolbarEventArgs>(CustomersScreen_ToolbarButtonClick);
      };
    }

    void CustomersScreen_ToolbarButtonClick(object sender, CustomerToolbarEventArgs e) {
      if (CustomersSet.SelectedItem != null) {
        CustomersSet.SelectedItem.CompanyName = e.Text;
      }
    }
  }
}

We only handle the one toolbar event, and just pull the required text from the CustomerToolbarEventArgs.

If you run this now, you’ll find that all three buttons modify the customer name property as expected.

After implementing this idea in my original application, the UI was much neater, as you can see from the screen shot below, and I had reduced the amount of code significantly. More to the point, maintenance was now pretty easy, as I had removed all the duplication.

My original Lightswitch application with the new toolbars in place

Obviously, there is a lot more that can be done here. The more I think about this, the more I realise that it opens up the possibilities of providing a custom UI for a Lightswitch application very easily, without requiring you to write a custom shell. Once again we see how Lightswitch gives you enormous leverage right out of the box, without sacrificing the flexibility that you need.

Categories: LightSwitch


In yesterday’s blog post, I introduced the Toast control that was added to the Pixata Custom Controls extension for Lightswitch. I mentioned at the end of the post that there were ways of creating much more flexible toasts. In this post, I’ll show you an example of what I meant. With only a little imagination, you should be able to tweak this little toasties to do almost anything!

The limitation with the method I showed yesterday is that it only allows you to set the title and message for the toast, and each of these has to be sent as plain text, without any formatting. In many cases, this is fine, but sometimes you want more control. The important thing to remember is that when you create your own toast, there is nothing to stop you from doing what you like with it before passing it to the ShowToast method. You can create a toast with any properties you like, populate those in your Lightswitch screen’s code-behind, and when you are done, pass it in to ShowToast. You are not limited to passing “new MyToast()” like I showed yesterday.

As an example, I’m going to assume you want to show a pop-up with some RSS feed information in it. I realise that this isn’t very likely from Lightswitch, but it was the first thing that sprang into my mind, partly inspired by finding a nice RSS icon on www.findicons.com. I called the new toast control ToastWithPeanutButter, mainly because I have a very childish sense of humour!

Create the basic control by following the instructions I showed yesterday.

Now, instead of restricting ourselves to two TextBlock controls for the title and message, we are going to do something a little more interesting for the message. Open up the ToastWithPeanutButter.xaml file, and replace the content with the following...

<uc:PixataToastControlBase x:Class="LightSwitchApplication.ToastWithPeanutButter"
                           xmlns:uc="clr-namespace:PixataCustomControls.Presentation.Controls;assembly=PixataCustomControls.Client"
                           xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
                           xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
                           xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
                           xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
                           mc:Ignorable="d"
                           d:DesignHeight="100"
                           d:DesignWidth="400">

  <Grid x:Name="LayoutRoot">
    <Grid.RowDefinitions>
      <RowDefinition Height="Auto" />
      <RowDefinition Height="*" />
    </Grid.RowDefinitions>
    <!-- Title bar -->
    <Grid HorizontalAlignment="Stretch"
          VerticalAlignment="Stretch">
      <Grid.ColumnDefinitions>
        <ColumnDefinition Width="*" />
        <ColumnDefinition Width="Auto" />
      </Grid.ColumnDefinitions>
      <Grid.Background>
        <LinearGradientBrush EndPoint="0.5,1"
                             StartPoint="0.5,0">
          <GradientStop Color="#FFE3EFF7"
                        Offset="0" />
          <GradientStop Color="#FFD6E7F3"
                        Offset="1" />
        </LinearGradientBrush>
      </Grid.Background>
      <TextBlock Name="TitleTb"
                 HorizontalAlignment="Center"
                 Text="Title"
                 FontWeight="Bold" />
      <Button VerticalAlignment="Center"
              HorizontalAlignment="Right"
              Grid.Column="1"
              Margin="5,3"
              Width="14"
              Height="14"
              Padding="0"
              Click="Button_Click">
        <Button.Content>
          <Image Source="/TestingPixataWithFerrets.Client;component/Images/closebutton.png"
                 Width="14"
                 Height="14"
                 HorizontalAlignment="Center"
                 VerticalAlignment="Center" />
        </Button.Content>
      </Button>
    </Grid>
    <!-- Main content area -->
    <Grid Grid.Row="1">
      <Grid.ColumnDefinitions>
        <ColumnDefinition Width="Auto" />
        <ColumnDefinition Width="*" />
      </Grid.ColumnDefinitions>
      <!-- tea cup RSS icon -->
      <Image Width="64"
             Height="64"
             Margin="8"
             VerticalAlignment="Center"
             HorizontalAlignment="Center"
             Source="/TestingPixataWithFerrets.Client;component/Images/rss.png" />
      <TextBlock Name="MainContentTb"
                 Grid.Column="1"
                 Margin="3"
                 Text="Main content" />
    </Grid>
    <Grid.Background>
      <LinearGradientBrush EndPoint="0.5,1"
                           StartPoint="0.5,0">
        <GradientStop Color="#FFFF9B00"
                      Offset="0" />
        <GradientStop Color="#FFF8D183"
                      Offset="1" />
      </LinearGradientBrush>
    </Grid.Background>
  </Grid>
</uc:PixataToastControlBase>

If you look at this in the Visual Studio designer, it will look like this...

The new toast in the VS designer

Looks pretty much like the previous ones eh? It is, but we are going to do one thing differently, and that will make a lot of difference.

Switch to the code behind, and override the TitleText property as before, as we are using a plain string for the title. However, instead of overriding the MessageText property, we are going to expose the MainContent TextBlock control, so that the calling code can manipulate it. Change the code to look like this...

using System.Windows;
using System.Windows.Controls;
using PixataCustomControls.Presentation.Controls;

namespace LightSwitchApplication {
  public partial class ToastWithPeanutButter : PixataToastControlBase {
    public ToastWithPeanutButter() {
      InitializeComponent();
    }

    public override string TitleText {
      set {
        TitleTb.Text = value;
      }
    }

    public TextBlock MainContent {
      get {
        return MainContentTb;
      }
    }

    private void Button_Click(object sender, RoutedEventArgs e) {
      CloseMe();
    }
  }
}

Notice that we don’t override the MessageText property, so anything we pass in for that parameter will not be used.

Our new toast is complete, let’s see how we can use it. In a Lightswitch screen code-behind, add the following...

Dispatchers.Main.BeginInvoke(() => {
  ToastWithPeanutButter toast = new ToastWithPeanutButter();
  TextBlock tb = toast.MainContent;
  tb.Text = "";
  tb.Inlines.Add(CreateRun("DotNetWhatNot - ", Bold: true));
  tb.Inlines.Add(CreateRun("7th Mar '12 16:42"));
  tb.Inlines.Add(new LineBreak());
  tb.Inlines.Add(CreateRun("Toast control added to Pixata Custom Controls for Lightswitch", ForeGround: Colors.Brown));
  tb.Inlines.Add(new LineBreak());
  tb.Inlines.Add(CreateRun("Some MSDN Blog - ", Bold: true));
  tb.Inlines.Add(CreateRun("7th Mar '12 17:31"));
  tb.Inlines.Add(new LineBreak());
  tb.Inlines.Add(CreateRun("Microsoft announce new version of VS - no Lightswitch!!", ForeGround: Colors.Brown));
  PixataToastHelper.ShowToast("Latest RSS feeds", "", toast, Width: 400, Height: 100);
});

For convenience, this uses the following utility method...

private Run CreateRun(string Text, int FontSize = 11, Color? ForeGround = null, bool Bold = false) {
  Run r = new Run {
    Text = Text,
    FontSize = FontSize,
    Foreground = (ForeGround == null ? new SolidColorBrush(Colors.Black) : new SolidColorBrush((Color)ForeGround)),
    FontWeight = (Bold ? FontWeights.Bold : FontWeights.Normal)
  };
  return r;
}

This utilises a little-known feature of the TextBlock control, that you can add formatted multiline text to it by manipulating the Inlines collection, which can take Run and LineBreak objects. Using this utility method, we build up a list of two RSS items, which in reality would be pulled from your data source. I hard-coded the information to keep the example simple.

The result of this is the following toast..

The new toast

That’s a definite improvement over yesterday’s toast!

Obviously, you don’t need to do all that work creating Run and LineBreak objects if you don’t want, you can just add more controls to the toast’s XAML, and expose their Text (or other) properties from the toast control. That way, the code you write in Lightswitch can set up the toast as you want before passing it to the ShowToast method.

I hope this post has whetted your appetite for creating more interesting toasts. If you have a toast that you feel would be useful to others, or just want to share an interesting creation, please let me know.

Categories: LightSwitch

I have just updated my Pixata Custom Controls extension for Lightswitch. Version 1.10 contains what I believe is the very first notification toast implementation for Lightswitch. As its usage differs from other controls, and it allows significantly more customisation than the others, I decided to write a blog post about it.

The simple usage of the control is to allow you to display a small notification window in the lower right-hand corner of the user’s screen (upper right-hand if they are using a Mac), which will not interfere with whatever they are doing, and will quietly go away after a short time. They are officially called “notification windows” but are colloquially known as toast, due to the way they pop up. One of the most famous uses of toast is when Microsoft Outlook informs you that you have a new email. This is a very user-friendly way of doing this, and is far better than the evil message boxes that plagued user interfaces for decades. If you still things message boxes are OK, please read some more about why they are evil and stop using them!

Imagine you were writing an application that maintained a list of ferrets (well, don’t we all?), and you wanted to notify the user when a new ferret had been added to the database. Instead of annoying them with a message box, you could simply pop up a notification like this...

A notification toast

The user can either ignore it, or click the close button to dismiss it.

I thought it would be really nice if we could have these in Lightswitch, and devoted the whole of today to developing a control to do just that.

Before I continue though, it’s worth pointing out that due to a limitation in the Silverlight API, toasts will only work in Out-Of-Browser applications. If you attempt to use this control in a browser, nothing will happen. Also, according to the documentation, you can’t have any interactive controls on the toast, although it was quite easy to add the close button (look at the top-right of the toast in the picture above), so I’m not sure that this is as restrictive as it sounds. Finally, the API does not give any control of the fade in/out duration, the shape of the toast (so no rounded corners), or the way the toast appears (eg sliding in as opposed to fading in), so we are stuck with the default behaviours in these respects. Having said that, there’s still a lot you can do with them, as I hope to show. With that aside, let’s see how to use the control.

Displaying Toast

If you have the latest version of the Pixata Custom Controls extension for Lightswitch, then all you need to do to display toasts is to switch to the code behind of the screen where you want the notification to appear. At the top of the file, add the following line...

using PixataCustomControls.Presentation.Controls;

You don’t need to worry about adding a reference to the controls, if you’ve enabled them in the Lightswitch project properties, then the reference will already be there.

To display the toast, you can do something as simple as this...

  PixataToastHelper.ShowToast("Title", "Type your message here");

This will display a fairly plain toast, using the title and message you supplied. Obviously, you can modify these to suit your needs, including data from the Lightswitch application.

If you want something a little more interesting, you can customise the toast by adding the following parameters to the call to ShowToast...

Parameter Meaning
ToastStyle There is an enumeration in the control that gives you five more styles for the toast. These are Info, Warning, Alert, Error and Elephant. The more observant readers may notice that the last one is a little out of place. This is because I was creating a custom style to show how easy it is to add your own (see below), and decided to leave it in as it amused me.

If you change the call to the following, you’ll end up with a toast that looks like the one shown above...

  PixataToastHelper.ShowToast("Ferret Information", "New ferret added 6th March '12, by user Freddy",
    PixataToastHelper.PixataToastStyles.Info);
Notice that last parameter? That sets one of the six predefined styles (including the default Plain style), and will be suitable for most purposes.
TimeOut This integer value specifies for how milliseconds the toast will be displayed before it disappears.

Due to limitations in the .NET API, this value cannot be less than zero (I believe Microsoft are working on time travel, but I don’t think it will be available until .NET 5 comes out), nor greater than 30000. Any values outside of this range will be modified to be between zero and 30000.
Width and Height These are pretty self-explanatory. Again, due to API limitations, toasts cannot be wider than 400 pixels, nor higher than 100 pixels. If you enter a value less than zero or greater than these maximum values, it will be modified.

That’s basically all there is to the standard usage. As you can see, very easy to use, but very effective.

However, you might look at these and say “I don’t like your designs, I want it different.” Well, that’s absolutely fine, because I added the capability for you to create your own toast styles! It’s a little more involved than the standard usage, but not much.

Creating Your Own Toast

The first thing you’ll need to do is to add a new Silverlight User Control to your Client project. For the purposes of this blog post, I’m going to show you how I built the Elephant style. Truth is, the only reason that style ended up in the extension is because once I had built it, I liked it enough to keep it! So, imagine you have called your control MyToast, although why you would do that is beyond me. I have no idea why Microsoft think that we all want our folders called My Documents, and My Viruses and so on. Anyway, I had a senior moment and called my sample control MyToast, so you’re going to have to live with that for this tutorial.

You will need to make a few changes to the control before you start designing your toast. Without boring you with the details, any toast control needs to be derived from a base control I wrote for the purpose. This allows you to pass the toast into the ShowToast method. At the top of the XAML, add a reference to the Pixata Custom Controls namespace, and then change the top-level tag from UserControl to uc:PixataToastControlBase as follows...

<uc:PixataToastControlBase x:Class="LightSwitchApplication.MyToast"
  xmlns:uc="clr-namespace:PixataCustomControls.Presentation.Controls;assembly=PixataCustomControls.Client"

I also like to add a design width and height, as these make it easier to work with when you’re designing the toast. The end of your opening tag should look like this...

  mc:Ignorable="d"
  d:DesignHeight="100"
  d:DesignWidth="400">

Now switch to the control’s code behind, and have the control inherit from PixataToastControlBase instead of UserControl. You’ll need to add the following using at the top of the file...

using PixataCustomControls.Presentation.Controls;

...and then change the class declaration as follows...

  public partial class MyToast : PixataToastControlBase {

At this stage, you can now happily design your toast. If you want to play along, here is the XAML for my elephant control...

<uc:PixataToastControlBase x:Class="LightSwitchApplication.MyToast"
                           xmlns:uc="clr-namespace:PixataCustomControls.Presentation.Controls;assembly=PixataCustomControls.Client"
                           xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
                           xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
                           xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
                           xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
                           mc:Ignorable="d"
                           d:DesignHeight="100"
                           d:DesignWidth="400">

  <Grid>
    <Grid.ColumnDefinitions>
      <ColumnDefinition Width="*" />
      <ColumnDefinition Width="100" />
    </Grid.ColumnDefinitions>
    <StackPanel Orientation="Vertical"
                Background="Black">
      <TextBlock Name="Title"
                 Text="The Title"
                 Margin="2,0"
                 HorizontalAlignment="Center"
                 FontWeight="Bold"
                 FontSize="14"
                 Foreground="White" />
      <Rectangle HorizontalAlignment="Stretch"
                 VerticalAlignment="Top"
                 Margin="5,0"
                 Fill="#FFC4C4C4"
                 Height="1" />
      <TextBlock Name="Message"
                 Text="The stuff on the toast that blathers on about nothing"
                 Margin="5,0"
                 VerticalAlignment="Top"
                 HorizontalAlignment="Left"
                 Foreground="White"
                 TextWrapping="Wrap" />
    </StackPanel>
    <Button Grid.Column="1"
            Padding="0"
            Click="Button_Click">
      <Button.Content>
        <Image Width="100"
               Height="100"
               Source="/TestingPixataWithFerrets.Client;component/Images/elephant100x100.png" />
      </Button.Content>
    </Button>
  </Grid>
</uc:PixataToastControlBase>

Obviously, you don’t have to add a picture of an elephant, but it won’t look as nice if you don’t! I found this one from www.findicons.com. Here’s how it looked in the Visual Studio designer...

The elephant toast in the VS designer

Notice that I’ve included a button in the XAML, and wired up the Click event. This allows the user to dismiss the toast before it times out. In this instance, the button is disguised as an elephant, which isn’t actually very user friendly. The Elephant toast style that comes with the control has a normal close button in the top right-hand corner of the toast, which is generally a better idea. People just aren’t used to the idea of clicking elephants yet!

Now, in order to get the title and message into your controls, you can override two string properties from the base class (actually from an interface that the base class implements, but let’s not split hairs)...

    public override string TitleText {
      set {
        Title.Text = value;
      }
    }

    public override string MessageText {
      set {
        Message.Text = value;
      }
    }

In this case, Title and Message are the names of the two TextBlock controls I put in the XAML. If you name yours differently, just modify this code.

The only other thing left to do is add a handler for the button’s Click event, which is used to allow the user to close the toast. Put the following code right below the two properties...

    private void Button_Click(object sender, RoutedEventArgs e) {
      CloseMe();
    }

CloseMe is a method in the base toast class that you inherited earlier, so you don’t need to write any more code than this.

Using The Toast In Lightswitch

Now you are ready to test your control. In your Lightswitch screen’s code behind, use the second overload of the ShowToast method, that takes your new toast control instead of a value from the enumeration. Note that as you are creating a control, you need to dispatch to the main thread, to avoid access violation exceptions. When using the built-in toast styles, you don’t need to worry about this as the control does it for you...

  Dispatchers.Main.BeginInvoke(() => {
    PixataToastHelper.ShowToast("Elephants!", "Watch out for the elephants!", new MyToast(), Width: 200, Height: 100);
  });

I have overridden the default width and height values here, and the result looks like this...

A notification toast

If you leave it alone, the toast will disappear after 4 seconds (as we didn’t override the default), or you can click the elephant and the toast will disappear immediately.

As mentioned above, it would be more intuitive to have the button look like a button, but I’ll leave that for you as an exercise. A slightly modified version of the elephant ended up in the extension.

As it stands, the control allows the display of a title and message. You can omit either of these if you wish, you just don’t override the appropriate property in your toast control’s code behind. Also, for those who find these two properties too limiting, there are ways of creating much richer, more flexible toast controls, but as this post is quite long already, I’ll leave that for another day.

I hope this is all clear, and you find the control useful. Please feel free to leave comments below.

Update 7th Mar: I have posted the follow-up article showing how to produce more advanced toasts.

Categories: LightSwitch

I was recently involved in a discussion on the Lightswitch forum, in which someone asked about updating the data in the view model before the current control lost focus. He was using a modal window that had only one text box on it, and wanted to set the enabled status of the OK button, depending on what was in the text box. The problem he had was that the ABCCanExecute method only fired when the text box lost focus, which couldn’t happen as there weren’t any other (enabled) controls on the window. I suggested an answer, which led me to remember a similar issue I had contemplated some time ago...

As part of my Pixata Custom Controls For Lightswitch extension, I wrote a control that displays a clickable web link. You can see the control to the right of the text box holding the web address in the screen shot below. If you click on the link, it would open the web page in your default browser.

The web link control on a Lightswitch screen

An issue I had with this was that when I changed the text in the text box, the clickable link would only be updated when the text box lost focus. I wanted the link to change as I typed.

I had a play with this today, and realised that whilst the answer is pretty simple, it might be worth blogging about it.

The way to get around this is to capture the TextChanged event of the text box, and manually update the view model data. The steps to do this are as follows:

1) In the InitializeWorkspace method of the screen, grab the text box (or strictly speaking, grab a proxy for it), and subscribe to the ControlAvailable event. This means that when Lightswitch paints the control on the screen (which might not always be as the screen is first displayed), you have access to the text box.

2) Save the text box in a private variable, so you can get at it later if you need to. This step isn’t strictly necessary, but I often do it as it comes in useful.

3) Subscribe to the text box’s TextChanged event, and in the handler, grab the updated text.

Here is some code that shows it in action...

   1:    partial void FerretsDetail_InitializeDataWorkspace(List<IDataService> saveChangesTo) {
   2:      var WebTextBox = this.FindControl("WebTextBox");
   3:      WebTextBox.ControlAvailable += new EventHandler<ControlAvailableEventArgs>(WebTextBox_ControlAvailable);
   4:    }
   5:
   6:    private TextBox webTextBox;
   7:    void WebTextBox_ControlAvailable(object sender, ControlAvailableEventArgs e) {
   8:      webTextBox = (TextBox)e.Control;
   9:      webTextBox.TextChanged += new TextChangedEventHandler(webTextBox_TextChanged);
  10:    }
  11:
  12:    void webTextBox_TextChanged(object sender, TextChangedEventArgs e) {
  13:      Ferrets.Web = webTextBox.Text;
  14:    }
  15:  }

On line 2, we get hold of the IContentItemProxy, which is basically something that stands in for the control until it is available. On line 3, we subscribe to the ControlAvailable event, which is on lines 7-10. Line 6 contains the declaration for the variable that will store the text box in case you need it later. On line 8, we pull the text box itself out of the event args that were passed in, and on line 9 we subscribe to the TextChanged event. Line 13 simply grabs the text form the text box, and pushes it into the Web property of the screen’s query (which in this case is called Ferrets).

The end result of this is that as you type in the web text box, the link text (and underlying address) is changed in real time.

This technique can be extended to do all sorts of clever things, removing some of the natural limitations of working in a Lightswitch screen.

Categories: LightSwitch
# Bjarne Stroustrup on computers and telephones (Tuesday, December 06, 2011)


"I have always wished for my computer to be as easy to use as my telephone; my wish has come true because I can no longer figure out how to use my telephone."

Danish computer scientist Bjarne Stroustrup

Categories: Computers
